Associated standards: BS 1363-2
Rated voltage: 250V
Rated current: 13A
Frequency: 50-60Hz
Wiring system: 2 pole
Min. switch contact gap: >1.2 mm
Ambient operating temperature: -5 to 40°C (24hour average not exceeding25°C)
Degree of protection: IP20
Terminal capacity: 3 x 2.5mm2 or 3 x 4mm2or 2 x 6mm2
Face plate material: urea-formaldehyde
Minimum wall box depth: 25
Nature of supply: AC
Fixing screws: M3.5x30mm
Max Installation Altitude?2000 meters
